0.03-2TPH Fish Feed Extruder Machine Dry Type

0.03-2TPH Fish Feed Extruder Machine Dry Type

Dry type fish feed extruder, also called fish feed pellet machine, is widely used for processing various materials into high-grade aquatic feed pellets for fish, catfish, shrimp, crab, lobsters, etc. Our fish feed machine can produce floating fish and sinking fish feed. Moreover, you can change extrusion degree to influence floating time. Without requiring steam boiler and with advanced single screw extruder, it is a primary choice of small and medium size feed processing plants and aqua farms.

FISH FEED SHAPE20180202193140

Dry Type Fish Feed Machine Spotlights

1. Meeting high quality need. The feed pellet produced by our machines are suitable for precious fish, aquarium fish, crevalle fish, shrimps, pet food, etc.
2. 0.9-15 mm size range. Different models can be chosen to make different size pellets according to your need.
3. High temperature and high pressure. During extruding process, the salmonellosis and bacterial infections can be killed, ensuring better digestibility.
4. Auto-temperature control system. Visual temperature controlling makes the parameter more precise.
5. Low investment. Without requiring steam boiler, its overall cost is lower. Besides, it is of less land occupation and easy to operate.
6. Multi-function. It can produce both floating and sinking fish feed pellet.
7. We also provide you the special usable aquatic feed formulations.


Working Principle of Dry Type Fish Feed Pellet Machine

The fish feed extruder is composed of feeding system, extruding system, cutting system and controlling system.

The specific process is: preheating(heating band of fish feed extruder)→ripening(with high temperature and pressure) →pellet making(die mould) →cutting (by high-speed cutter).

Parameters of Dry Type Floating Fish Feed Machine

Model Capacity
(kg/h)
Main
Power
(kw)
Feeder
power

(kw)
Cuter
power

(kw)
Diameter
of screw
(mm)
DGP50 60-80 11 0.4 0.4 50
DGP60 100-150 15 0.4 0.4 60
DGP70 180-200 18.5 0.4 0.6 70
DGP80 300-350 22 0.6 0.6 80
DGP90 400-450 37 1.1 1.5 90
DGP120 500-700 55 1.1 2.2 120
DGP135 800-1000 75 1.1 2.2 135
DGP160 1000-1500 90 1.1 2.2 160
DGP200 1800-2000 132 2.2 4.0 200

We are glad to inform you that the machines in our company are produced according to countries or areas.
In order to provide better service and products with you,it's our honor to have the below info about you.

1,Where will your Project Build?
2,How much your Budget?
3,What is your Raw materials___? their size length___width___Thickness___and mositure percent___?
4,Do you need only the Pellet Mill or a Complete Pellet Production lines?
5,What is the Capacity(Ton/Hour) you need?
6,What's your use about the pellet,for burning or feeding animals?
Any other DETAIL request,just let us know.
